In my last blog post I introduced the Common Instance Factory, which I built as an alternative to Common Service Locator to reduce coupling between an application and a Dependency Injection (DI) container.  Unlike the Common Service Locator (CSL), the Common Instance Factory (CIF) discourages the service location anti-pattern by using the abstract factory design pattern.

I would venture to say that in many cases, introducing this additional layer of abstraction is not always necessary.  If you are careful to register your types early in the startup of your application and avoid referencing the DI container from within your types (which is where the service location ant-pattern rears its ugly head), then selecting a DI container and sticking with it might be perfectly appropriate.  And I would certainly not use CIF for unit tests (or even some integration tests), where you need to leverage features of the DI container that are not exposed via the factory interface.

There are other situations, however, when wrapping the DI container with the CIF will give you the kind of decoupling and flexibility you want in your application architecture. This layer of abstraction can be especially advantageous, for example, when building ASP.NET apps or WCF services where performance is a critical factor. In this case, you might want to use a super-fast DI container, such as SimpleInjector, for the application while leveraging a full-featured DI container, just as Ninject, for unit testing.

The NuGet package, CommonInstanceFactory.Extensions.Wcf, provides the building blocks for hosting WCF services which are decoupled from a particular DI container. The first component is the InjectedInstanceProvider, which implements the WCF interface, IInstanceProvider, using ICommonInstanceFactory to retrieve and release instances from the DI container (see my prior blog post for more information on ICommonInstanceFactory).

public class InjectedInstanceProvider<TServiceType> : IInstanceProvider
    where TServiceType : class
{
    private readonly ICommonInstanceFactory<TServiceType> _container;

    public InjectedInstanceProvider(ICommonInstanceFactory<TServiceType> container)
    {
        _container = container;
    }

    public object GetInstance(InstanceContext instanceContext, Message message)
    {
        return GetInstance(instanceContext);
    }

    public object GetInstance(InstanceContext instanceContext)
    {
        TServiceType service = _container.GetInstance();
        return service;
    }

    public void ReleaseInstance(InstanceContext instanceContext, object instance)
    {
        var service = instance as TServiceType;
        if (service != null)
        {
            try
            {
                _container.ReleaseInstance(service);
            }
            finally
            {
                var disposable = instance as IDisposable;
                if (disposable != null)
                {
                    disposable.Dispose();
                }
            }
        }
    }
}

If the underlying DI container does not implement ReleaseInstance, no harm no foul. Notice how ReleaseInstance checks to see if the service type implements IDisposable and, if so, calls Dispose on it. (This behavior happens to be missing from Ninject’s WCF extension, but CIF provides the correct implementation.)

Next, the CIF extension for WCF supplies an InjectedServiceBehavior, whose job it is to plug the InjectedInstanceProvider into the WCF pipeline.

public class InjectedServiceBehavior<TServiceType> : IServiceBehavior
    where TServiceType : class
{
    private readonly ICommonInstanceFactory<TServiceType> _container;

    public InjectedServiceBehavior(ICommonInstanceFactory<TServiceType> container)
    {
        _container = container;
    }

    public void ApplyDispatchBehavior(ServiceDescription serviceDescription, ServiceHostBase serviceHostBase)
    {
        foreach (ChannelDispatcherBase cdb in serviceHostBase.ChannelDispatchers)
        {
            var cd = cdb as ChannelDispatcher;
            if (cd != null)
            {
                foreach (EndpointDispatcher ed in cd.Endpoints)
                {
                    ed.DispatchRuntime.InstanceProvider
                        = new InjectedInstanceProvider<TServiceType>(_container);
                }
            }
        }
    }
}

Lastly, there is the InjectedServiceHostFactory abstract class, which container-specific adapters will need to implement to initialize a container and return a container-specific ServiceHost.

public abstract class InjectedServiceHostFactory<TContainer> : ServiceHostFactory
    where TContainer : class
{
    protected abstract TContainer CreateContainer();

    protected abstract ServiceHost CreateInjectedServiceHost
        (TContainer container, Type serviceType, Uri[] baseAddresses);

    protected override ServiceHost CreateServiceHost(Type serviceType, Uri[] baseAddresses)
    {
        TContainer container = CreateContainer();
        ServiceHost serviceHost = CreateInjectedServiceHost
            (container, serviceType, baseAddresses);
        return serviceHost;
    }
}

Here is an example of a class that extends InjectedServiceHostFactory by implementing its abstract methods.  This class would most likely reside in a WCF host (such as a web project) or an assembly referenced by a host, because it needs to initialize the container by registering dependencies that are specific to the application – in this case via the GreetingModule.

public class NinjectServiceHostFactory : InjectedServiceHostFactory<IKernel>
{
    protected override IKernel CreateContainer()
    {
        IKernel container = new StandardKernel();
        container.Load<GreetingModule>();
        return container;
    }

    protected override ServiceHost CreateInjectedServiceHost
        (IKernel container, Type serviceType, Uri[] baseAddresses)
    {
        ServiceHost serviceHost = new NinjectServiceHost
            (container, serviceType, baseAddresses);
        return serviceHost;
    }
}

Here is how CommonInstanceFactory.Extensions.Wcf.Ninject extends ServiceHost with by providing NinjectServiceHost, which accepts a container to create a NinjectInstanceFactory and adds the InjectedServiceBehavior to the ServiceHost’s Description.

public class NinjectServiceHost<TServiceType> : ServiceHost
    where TServiceType : class
{
    public NinjectServiceHost(IKernel container, Type serviceType, params Uri[] baseAddresses)
        : base(serviceType, baseAddresses)
    {
        ICommonInstanceFactory<TServiceType> instanceFactory
            = new NinjectInstanceFactory<TServiceType>(container);
        Description.Behaviors.Add(new InjectedServiceBehavior<TServiceType>(instanceFactory));
    }
}

Lastly, here is an example of a Service.svc file which references the container-specific NinjectServiceHostFactory.  (The non-generic version of NinjectServiceHost uses a little reflection magic to instantiate the generic NinjectInstanceFactory<TServiceType>.)

<%@ ServiceHost Factory="CommonInstanceFactory.Sample.Hosting.Web.ServiceHostFactories.NinjectServiceHostFactory"
                Service="CommonInstanceFactory.Sample.Services.GreetingService" %>

When you want to change from one DI container to another, all you need to do is replace the Factory attribute with the ServiceHostFactory of the new container.  For example, here is a Service.svc which references the SimpleInjectorServiceHostFactory.

<%@ ServiceHost Factory="CommonInstanceFactory.Sample.Hosting.Web.ServiceHostFactories.SimpleInjectorServiceHostFactory"
                Service="CommonInstanceFactory.Sample.Services.GreetingService" %>

If you have a non-web host, such as a Windows Service, you won’t need to worry about wiring up a container-specific ServiceHostFactory at all.  Instead, you can simply initialize the container yourself and pass it directly to the constructor of the container-specific ServiceHost.

ServiceHost serviceHost;
var serviceBaseAddress = new Uri("http://localhost:8000/GreetingService");
switch (containerType)
{
    case ContainerType.Ninject:
        serviceHost = new NinjectServiceHost<GreetingService>
            (CreateNinjectContainer(), typeof(GreetingService), serviceBaseAddress);
        break;
    case ContainerType.SimpleInjector:
        serviceHost = new SimpleInjectorServiceHost<GreetingService>
            (CreateSimpleInjectorContainer(), typeof(GreetingService), serviceBaseAddress);
        break;
}

Using the Common Instance Factory, switching DI containers is relatively painless, and you’ll get a layer of abstraction from the DI container that will help decouple your WCF services from any particular container.  To get CIF, download the NuGet CIF packages. To see examples of using CIF with WCF extensions, download samples and source code from the CIF CodePlex site. Enjoy.

Download the Common Instance Factory with WCF Extensions here and is also available on NuGet.

A while back I wrote a blog post on the Onion Architecture, an approach to building loosely-coupled applications where you can swap out particular components without affecting the rest of the application.  They key to making it all work is the use of Dependency Injection, also known as Inversion of Control, to delegate creation of types to an external container.  There are various ways to implement dependency injection, but the most common is a technique called “constructor injection,” in which a class provides a constructor that accepts one or more interfaces as parameters.  Concrete implementations of each interface are registered with the DI container and supplied to the constructor when a request for the type is made from the container.

public class GreetingService : IGreetingService
{
    private readonly IGreetingRepository _greetingRepository;

    public GreetingService(IGreetingRepository greetingRepository)
    {
        _greetingRepository = greetingRepository;
    }

    public string Greet(string name)
    {
        string greeting = _greetingRepository.GetGreeting();
        return string.Format("{0} {1}", greeting, name);
    }
}

In this example, an IGreetingRepository is passed to the GreetingService’s constructor.  GreetingService doesn’t care how IGreetingRepository is implemented.  It’s the job of the DI container to provide whichever implementation of IGreetingRepository was registered with the container.  This promises the architect’s nirvana of loose coupling, because the GreetingService is abstracted away from the implementation of IGreetingRepository, which allows you to switch from one persistence stack to another without affecting parts of the application which depend on it.

Ah, but there’s a problem. You have to select a DI container from one of numerous proprietary and open-source products on the market and then marry yourself to it.  You are then tightly coupled to the DI container!  Now, there are some best practices when it comes to using a DI container, which make it less traumatic to switch from one to another, such as registering dependencies at the composition root, or entry point, of the application.  Still, placing a layer of abstraction between your application and the DI container allows for greater flexibility, which is what loose-coupling is all about.

Until recently, I was content to select a DI container, based on its features and ease-of-use, and learn to live with it.  Then I started looking at performance benchmarks for various DI containers.  It turnes out my favorite container, Ninject, was one of the worst performing.  So it was time to look at switching to another container for the application I was writing.  This didn’t mean, however, I had to jettison Ninject altogether.  A lot of DI-specific code is needed for unit tests, where there is extensive mocking, and advanced features of a DI container such as Ninject come in handy.

When searching for a way to abstract away the DI container, the first solution I examined was the Common Service Locator, built by Microsoft’s Patterns and Practices group back in 2008 with the source code posted on CodePlex.  However, I found a couple of deficiencies. First, and most egregious, is that it is modeled as a service locator, rather than an abstract factory.  In his article, Inversion of Control Containers and the Dependency Injection Pattern, Martin Fowler describes some of the weaknesses of the service locator anti-pattern.  He states, “With a Service Locator every user of a service has a dependency to the locator,” and that “the locator can hide dependencies to other implementations.”

The problem arises when a class directly references the locator, using it to instantiate types it depends on, which creates a dependency on the locator and hides the actual dependencies of the class.  While it is possible to use the Common Service Locator without falling into this trap, the base interface, IServiceLocator, is a non-generic interface with a generic method that allows you to create an infinite number of types, making it easier for classes to use it directly.

This was undoubtedly a design-decision by the MS team to achieve a wider adoption by making the Common Service Locator compatible with both dependency injection and service location frameworks. However, a cleaner alternative is the abstract factory pattern, which can be expressed as a generic interface with a method that only return instances of a single type.  This discourages folks from using the factory for service location and instead promotes the dependency injection pattern described by Martin Fowler.

Another weakness of Common Service Locator is that it does not provide a ReleaseInstance method.  Some containers manage the lifetime of instances internally and there needs to be a way to ask a container to release an instance under its control.

This led me to develop the Common Instance Factory, as an alternative to the Common Service Locator, and to extend it with support for WCF services that are decoupled from any particular DI container.  Notice it’s a “factory” versus “locator” and that it produces “instances” instead of “services” (while technically more accurate, I found the term “service” to be overused and sometimes misleading).  Here is the root interface used for resolving instances.

public interface ICommonInstanceFactory<TInstance>
{
    TInstance GetInstance();
    IEnumerable<TInstance> GetAllInstances();
    void ReleaseInstance(TInstance instance);
}

The base implementation is an abstract class with methods which container-specific adapters need to override.

public abstract class CommonInstanceFactoryBase<TInstance> : ICommonInstanceFactory<TInstance>
    where TInstance : class
{
    public TInstance GetInstance()
    {
        return InternalGetInstance();
    }

    public IEnumerable<TInstance> GetAllInstances()
    {
        return InternalGetAllInstances();
    }

    public void ReleaseInstance(TInstance instance)
    {
        InternalReleaseInstance(instance);
    }

    protected abstract TInstance InternalGetInstance();
    protected abstract IEnumerable<TInstance> InternalGetAllInstances();
    protected abstract void InternalReleaseInstance(TInstance instance);
}

To start with, I’ve written two adapters, one for Ninject (slow but with a lot of features) and one for SimpleInjector (fast but with fewer features).  The implementation of the abstract base class is quite straightforward, so there’s not much effort required to write adapters for other DI containers. (Stay tuned for more!)  Here’s the Ninject adapter.

public class NinjectInstanceFactory<TInstance> : CommonInstanceFactoryBase<TInstance>
    where TInstance : class
{
    private readonly IKernel _container;

    public NinjectInstanceFactory(IKernel container)
    {
        _container = container;
    }

    protected override TInstance InternalGetInstance()
    {
        var instance = _container.Get<TInstance>();
        return instance;
    }

    protected override IEnumerable<TInstance> InternalGetAllInstances()
    {
        var instances = _container.GetAll<TInstance>();
        return instances;
    }

    protected override void InternalReleaseInstance(TInstance instance)
    {
        _container.Release(instance);
    }
}

To use it all you have to do is new up the NinjectInstanceFactory, supplying an initialized container to the constructor.  Here is a unit test that demonstrates the usage.

[TestFixture]
public class NinjectAdapterTests
{
    private IKernel _container;

    [TestFixtureSetUp]
    public void TestSetup()
    {
        _container = new StandardKernel();
        _container.Load<GreetingModule>();
    }

    [Test]
    public void Ninject_Adapter_Should_Get_GreetingService()
    {
        // Arrange
        var resolver = new NinjectInstanceFactory<GreetingService>(_container);

        // Act
        var greeter = resolver.GetInstance();
        string greeting = greeter.Greet("Tony");

        // Assert
        Assert.That(greeting, Is.StringMatching("Howdy Tony"));
    }
}

So far, this really isn’t that big of a deal.  The client still needs to initialize the container and pass it to the instance factory.  So what’s the advantage?  The power of the abstraction comes to the fore when using dependency injection with frameworks such as ASP.NET MVC or WCF.  Particularly with WCF, where you need other pieces (such as an instance provider, service behavior and service host), the abstraction afforded by the Common Instance Factory provides a uniform way to deal with different DI containers so that swapping out one for another is much easier.  That will be the topic of my next blog post.

Download the Common Instance Factory from NuGet, or get the source code and samples from the CodePlex site.
